Description
EC21-E / EC21-V Mini PCIe overview
Quectel EC21-E / EC21-V Mini PCIe supports LTE Cat 1 integration for equipment such as meters, gateways and tracking systems. The family reference specifies up to 10 Mbps downlink and 5 Mbps uplink on LTE-FDD. Select the regional suffix, hardware revision and firmware for your host and target network.
Model and supply configuration
The photograph shows a card carrying an EC21-E module labeled EC21EFA-512-STD. The retained catalogue SKU and URL identify EC21-V Mini PCIe. Select EC21-E or EC21-V explicitly; the photograph is not evidence of an EC21-V card or the complete card ordering code.
| Sales form | Mini PCIe card; separate from a bare solder-down module, USB dongle or evaluation kit. |
|---|---|
| Complete ordering code | Confirm the full module or card P/N, hardware revision, firmware and quantity with the quotation. Historical photographs do not confirm current batch availability. |
| Supplied items | Confirm packaging, antennas, cables, adapters and evaluation accessories in the quotation; they are not automatically included. |
Variant-specific reference
Source: Quectel EC21 Series Mini PCIe LTE Standard Specification V1.7, Chinese controlled-document copy, copyright 2023, pages 2-3. Current official family overview checked 2026-09-13. Values below are a revision-specific selection reference, not a supply-batch test report.
EC21-E Mini PCIe
| Intended region | EMEA / Thailand / India; confirm operator bands and deployment acceptance separately. |
|---|---|
| LTE-FDD bands | B1/3/5/7/8/20 |
| LTE-TDD bands | None |
| WCDMA bands | B1/5/8 |
| GSM / EDGE bands | B3/8 |
EC21-V Mini PCIe
| Intended region | US regional variant; confirm operator bands and deployment acceptance separately. |
|---|---|
| LTE-FDD bands | B4/13 |
| LTE-TDD bands | None |
| WCDMA bands | None |
| GSM / EDGE bands | None |
| Dimensions | 51.0 x 30.0 x 4.9 mm |
|---|---|
| Supply voltage | 3.0-3.6 V; typical 3.3 V. Confirm the card pinout and host power sequencing. |
| Temperature | Operating -35 to +75 C; extended -40 to +80 C. |
| LTE-FDD theoretical rate | 10 Mbps downlink / 5 Mbps uplink. Real performance depends on network, signal and implementation. |
| Interfaces | USB 2.0, UART, (U)SIM and PCM are listed for the card family. Mini PCIe shape alone does not establish host electrical or driver compatibility. |
| GNSS | Optional in the cited variant table. Confirm the ordering option, antenna and firmware before specifying positioning. |
| Voice and software | Voice/VoLTE are optional; confirm firmware and network support. Use a driver validated for the target OS and kernel. Features marked under development in old documents are not guaranteed. |
Use only the fallback technologies listed for the selected suffix and available on the target network. Extended temperature operation has document-specific performance conditions; it is separate from the normal operating range. Form-factor compatibility with EC25, EG25-G or other modules is not a promise of direct replacement.
Technical documents and compliance
- Quectel official EC21 Mini PCIe product and technical resources.
- Reference used for this table: EC21 Series Mini PCIe LTE Standard Specification V1.7, pages 2-3. Request the matching full revision with your enquiry.
- The official resource list includes EC21 Series Mini PCIe Hardware Design V1.7 behind login. Obtain the card-specific manual; a bare-module hardware manual does not define the card input or pinout.
Manufacturer specifications contain regional approval summaries. Certificates, supplier declarations and test reports serve different purposes and must match the exact part, revision and destination. Request applicable documents after enquiry; this page does not claim that a historical certificate establishes the current certification of the quoted item or final host.
Related selection and enquiry
- EC21-E / EC21-EU – review the separate suffix and hardware form.
- EC21-A – review the separate suffix and hardware form.
Send the required full part number, quantity, country/operator, host platform, bands and GNSS/voice needs with your BOM enquiry. Confirm the current quotation and accessory list during follow-up. Visit the Datasheet Center for related references.
